Displacement: 160~400cc/rev
Max.differential pressure: 400~450 bar
| Series | HRP03 | ||||||||
| Motor performance | |||||||||
| Displacement | cm3/rev. | 160 | 225 | 255 | 325 | 365 | 400 | ||
| Max.torque | N·m | 1145 | 1611 | 1826 | 2069 | 2323 | 2546 | ||
| Min.stable speed | rpm | 5 | |||||||
| Max.speed | Displacement | rpm | 670 | 475 | 420 | 330 | 295 | 270 | |
| Variable displacement | rpm | 875 | 620 | 550 | 430 | 385 | 350 | ||
| Pressure | Max.differential pressure | bar | 450 | 400 | |||||
| Max.power | kW | 18 | 22 | ||||||
| Weight | Single speed | With brake | kg | 35.202 | |||||
| Without brake | kg | 25.6 | |||||||
| Two speed | With brake | kg | 39.9 | ||||||
| Without brake | kg | 30.281 | |||||||
| Brake | |||||||||
| Static braking torque | N·m | 2200 | |||||||
| Release pressure | bar | 15 ~ 30 | |||||||
| Maximum pressure at brake port Z | bar | 30 | |||||||
| Oil volume to operate brake | cm3 | 23 | |||||||
